5.5 Inch SPI TFT Touch Screen Module IPS LCD Display 720x1440 High Definition

Brand Name : RGH

Model Number : RT55HD011A

Certification : ISO9001/ISO14001

Place of Origin : Shenzhern,China

MOQ : 3PCS

Price : Negotiable

Payment Terms : L/C, T/T,Paypal

Supply Ability : 3.5kk

Delivery Time : 3-5weeks

Packaging Details : Standard Exportation Package

Screen Size : 5.5 inch

Resolution : 720（RGB）X1440

Display Type : TFT LCD

Brightness : 1050cd/m²

Weight : TBD

Response Time : 30ms

Viewing Angle : ALL o’clock

Backlight Type : LED

Contrast Ratio : 1500:1

Number of Dots : 720（RGB）X1440

Active area : 61.88(H) X123.77(V)

Operating temperature : -20℃~70℃

Storage temperature : -30℃~80℃

Driving IC : ST7703I-G5-DP

Voltage for logic : 2.5V-3.3V

Color : 262K

Interface : MIPI

Dimensions : 65.02(H) X131.43(V) X3.06(T) mm

Contact Now

5.5 Inch SPI TFT Touch Screen Module IPS LCD Display 720x1440 High Definition

NO.	Symbol	Level	Function
1-2	LEDA2		LED anode
3-4	LEDK2		LED cathode
5-10	NC		NC
11	GND		Ground
12-13	VDD		Power setting
14-15	IOvCC		A supply voltage tothe digital circuit.Connect to an external power supplyof1.65~3.3V
16	GND		Ground
17	RESET		Initialize the chip with a low input.Be sure toexecute a power-on reset after supplying power.
18	GND		Ground
19	D3P		MIPI DSI differential data pair.
20	D3N		MIPI DSI differential data pair.
21	GND		Ground
22	D2P		MIPI DSI differential data pair.
23	D2N		MIPI DSI differential datapair.
24	GND		Ground
25	CLKP		MIPI DSI diffe rential clock pair.
26	CLKN		MIPI DSI differential clockpair.
27	GND		Ground
28	D1P		MIPI DSI differential data pair.
29	D1N		MIPIDSI differential data pair.
30	GND		Ground
31	D0P		MIPI DSI differential data pair.
32	D0N		MIPIDSI differential data pair.
33-34	GND		Ground
35	TP-RST		TP-RST
36	TP-INT		TP-INT
37	TP-SDA		TP-SDA
38	TP-SCL		TP-SCL
39	TP-GND		TP-GND
40	TP-VDD		TP-VDD

5.5 Inch SPI TFT Touch Screen Module IPS LCD Display 720x1440 High Definition

FAQ

1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.

2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).

3. Do you support custom logo on the LCM?

A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.

4. How can I place a sample order?

A: Pls send us your inquiry, our sales will contact you soon.

5. What size LCD display can you provide?

A: 0.96 inch to 21.5 inch TFT LCD display we can provide.

7. What's your MOQ?

A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.

8. What shipping ways do you support?

A: We can consult with it.
